PRODUCT
UL 498 American Female Nema Receptacle Electrical Sockets AC Power Outlet Inlet 15A 125V AC 3 Pole With 94V-0 Ratings
Product Attributes :
Specifications
Socket Type: American Electrical Socket
Rated Current: 15A
Voltage Ratings: 125VAC
Standard: UL 498
Insulation Res.: 100MΩ 500V DC/1 Minute
Dielectric Strength: 2000V AC/1 Minute
Housing Material: Thermoplastic 94V-2~V-0
Color: Black Or White
Product Description
Product Description
UL 498 American Female Nema Receptacle Electrical Sockets AC Power Outlet Inlet 15A 125V AC 3 Pole With 94V-0 Ratings
Features
Standard: UL 498
Rating:15A 125V AC
Insulation Resistance: 100MΩ 500V DC/1 minute
Dielectric Strength: 2000V AC/1 minute
Housing Material: Thermoplastic 94V-2~V-0
