2.2 mH ±30% Common Mode Filter Ferrite Toroidal Inductor 16A Idc 7.1mΩ Rdc Magnetic Core Toroidal Power Line Choke Coil
Product Attributes :
Specifications
Coil Type: Common Mode Inductor
Inductance: 2.2mH
Ref Cross: B82726S2163N030
Max DC Current: 16A
Mounting Type: Radial
Max Resistance: 7.1mΩ
Tolerance: ±30%
Core Material: Ferrite
Max. Frequency: 10 KHz
Terminal Type: PC Pin
Product Description
Product Description
2.2 mH ±30% Common Mode Filter Ferrite Toroidal Inductor 16A Idc 7.1mΩ Rdc Magnetic Core Toroidal Power Line Choke Coil
General
26S Series Toroidal Inductors
26S3543N040 Series are Current-Compensated Ring Core double choke with a Ferrite Core
Polycarbonate base plate and spacer (UL 94 V-0)
Sector winding
Suitable for wave soldering
Approx. 1% stray inductance for symmetrical interference suppression thus ideal for
Suppression of common-mode interferences and in Switch-mode applications
Electrical Parameters
| Part number | Inductance | A | B | C | D | working frequency |
| T16-26,52 | 1.0uH-10.0uH | 6 | 3.5 | 6 | 2.5 | 10.0-100.0KHZ |
| T20-26,52 | 1.0uH-10.0uH | 7 | 4 | 7 | 3 | 10.0-100.0KHZ |
| T25-26,52 | 1.0uH-15.0uH | 8.5 | 4.5 | 8.5 | 3.5 | 10.0-100.0KHZ |
| T26-26,52 | 1.0uH-25.0uH | 8.5 | 7 | 8.5 | 6 | 10.0-100.0KHZ |
| T30-26,52 | 2.0uH-30.0uH | 10 | 5.5 | 10 | 4.5 | 10.0-100.0KHZ |
| T37-26,52 | 2.0uH-35.0uH | 12 | 5.5 | 12 | 4.5 | 10.0-100.0KHZ |
| T38-26,52 | 2.0uH-45.0uH | 12 | 7 | 12 | 6 | 10.0-100.0KHZ |
| T44-26,52 | 3.0uH-50.0uH | 13 | 6 | 13 | 5 | 10.0-100.0KHZ |
| T50-26,52 | 5.0uH-60.0uH | 15 | 8 | 15 | 6 | 10.0-100.0KHZ |
| T51-26,52 | 5.0uH-60.0uH | 12 | 8.5 | 12 | 7 | 10.0-100.0KHZ |
| T60-26,52 | 5.0uH-70.0uH | 18 | 8.5 | 18 | 7 | 10.0-100.0KHZ |
| T68-26,52 | 5.0uH-75.0uH | 21 | 8.5 | 21 | 7 | 10.0-100.0KHZ |
| T72-26,52 | 5.0uH-75.0uH | 21 | 9 | 21 | 7 | 10.0-100.0KHZ |
| T80-26,52 | 5.0uH-80.0uH | 24 | 9 | 24 | 8 | 10.0-100.0KHZ |
| T90-26,52 | 5.0uH-80.0uH | 27 | 13 | 27 | 11 | 10.0-100.0KHZ |
| T94-26,52 | 5.0uH-80.0uH | 27 | 11 | 27 | 9 | 10.0-100.0KHZ |
| T106-26,52 | 5.0uH-80.0uH | 31 | 14 | 31 | 12 | 10.0-100.0KHZ |
| T130-26,52 | 0.5mH-3.0mH | 36 | 14 | 36 | 12 | 10.0-100.0KHZ |
| T131-26,52 | 0.5mH-3.0mH | 36 | 14 | 36 | 12 | 10.0-100.0KHZ |
| T141-26,52 | 0.7mH-3.2mH | 39 | 14 | 39 | 12 | 10.0-100.0KHZ |
| T150-26,52 | 1.0mH-3.5mH | 42 | 14 | 42 | 12 | 10.0-100.0KHZ |
| T157-26,52 | 1.0mH-3.5mH | 43 | 17 | 43 | 15 | 10.0-100.0KHZ |
| T175-26,52 | 1.0mH-3.7mH | 48 | 19 | 48 | 17 | 10.0-100.0KHZ |
| T184-26,52 | 1.0mH-3.5mH | 51 | 22 | 51 | 19 | 10.0-100.0KHZ |
| T200-26,52 | 2.0mH-4.0mH | 55 | 28 | 55 | 26 | 10.0-100.0KHZ |
| T201-26,52 | 2.0mH-4.0mH | 55 | 25 | 55 | 23 | 10.0-100.0KHZ |
| T225-26,52 | 2.0mH-4.0mH | 60 | 18 | 60 | 16 | 10.0-100.0KHZ |
| T250-26,52 | 2.0mH-4.0mH | 68 | 30 | 68 | 27 | 10.0-100.0KHZ |
| T300-26,52 | 2.0mH-4.0mH | 81 | 40 | 81 | 25 | 10.0-100.0KHZ |
| T400-26,52 | 2.0mH-4.0mH | 115 | 50 | 115 | 30 | 10.0-100.0KHZ |
